Bandpass Filters
#Edge Filters
#Notch Filters
#Dichroic Mirrors
#Others
#Customized Optical Coating
#
| Product Description | Bandpass Filter BP405-10 |
| Center Wavelength/nm | 405±2 |
| FWHM (nominal)/nm | 10±2 |
| Passband/nm | T>90%@405±2 |
| Stopband/nm | OD≥6@250-1000 |
| Angle of Incidence | 0 |
| Transverse Dimensions (diameter) | 25 mm |
| Transverse Tolerance | + 0.0 / – 0.1 mm |
| Filter Thickness (mounted) | 3.5 mm |
| Filter Thickness Tolerance (mounted) | ± 0.1 mm |
| Clear Aperture | ≥ 22 mm |
| Scratch-Dig | 60-40 |
