| Product Description | Bandpass Filter BP430-24 |
| Center Wavelength/nm | 430±2 |
| FWHM (nominal)/nm | 24±2 |
| Passband/nm | T>90%@430±8 |
| Stopband/nm | OD≥6@350-1000 |
| Angle of Incidence | 0 |
| Transverse Dimensions (diameter) | 25 mm |
| Transverse Tolerance | + 0.0 / – 0.1 mm |
| Filter Thickness (mounted) | 3.5 mm |
| Filter Thickness Tolerance (mounted) | ± 0.1 mm |
| Clear Aperture | ≥ 22 mm |
| Scratch-Dig | 60-40 |
